Tektronix 7844 Dual-Beam Oscilloscope
| Name | Tektronix 7844 Dual-Beam Oscilloscope |
|---|---|
| Owner | Makers' Alliance |
| Location | Electronics |
| Training needed | No |
| Hackable | No |
| Model | 7844 |
| Serial | UNKNOWN |
| Arrival Date | 2022 |
| Working | No |
| Contact | Sam Harmon |
Current Status: Partially Functional
Specifications:
- Bandwidth: 400 MHz
Has 7A22 (differential amplifier), 7A26 (dual trace amplifier), 7B85 (delaying time base) and 7B80 (time base) plug-ins.
We have gotten at least one trace to display. It may need some more work to get fully functional.
